Name: Single-Layer Aluminum PCB - 1.0mm 1oz MCPCB | Custom PCB Manufacturing
Availability: InStock
Rating: 4.5 (89 reviews)

Description

Data sheet

Model: Aluminum LED strip PCB
Layer: 1
Material: Aluminium PCB
Finished Board Thickness: 1.0mm
Finished Copper thickness: 1OZ
Min Line Width/Space: ≥3mil(0.075mm)
Min Hole: ≥4mil(0.1mm)
Surface Finish: LF-HASL
Solder Mask Color: White
Legend Color: Black
Application: LED strip

About Single-Layer PCB

Single-Layer PCB: This PCB consists of a single layer of aluminum substrate PCB, they are comparatively simple in design and used in applications where heat management is the main concern. Some applications are LED lighting, automotive electronics, power supplies etc.

Applications

Surgical Lighting Tools

High-power Scanners

Electronic Control

Power Transmission Systems

Automotive Dashboards

Power Modules

Interior Lighting

Audio Equipments

Landscape Lighting

Get in Touch

If you have any camping barbeque equipment inquiry, please feel free to contact us.

Single-Layer Aluminum PCB

This PCB consists of a single layer of aluminum substrate PCB, they are comparatively simple in design and used in applications where heat management is the main concern.

Product Details Contact Now
