Industrial Controller PCB

Parameter

• Substrate Type: High Tg FR-4/Polyimide

• Copper foil thickness: 3OZ

• Impedance tolerance: ± 5%

• Insulation resistance: ≥ 10Ω

• Dielectric loss (Df): ≤ 0.02 (1GHz)

• Operating temperature: – 40 ℃~+125 ℃

• Min line width/line distance: 3/3mil

• Min aperture: 0.15mm (laser blind hole)

• Surface treatment: ENIG/HASL

• Compliance certification: ISO 9001, IATF 16949, UL94 V-0


The industrial controller PCB is the core hardware carrier for industrial controllers. As the operational hub, it not only hosts core components such as MCU/CPU main control chips and memory components but also accurately processes analog/digital signals. It integrates industrial bus interfaces like RS485 and EtherCAT to enable data acquisition, command output, and device interconnection.



With industrial-grade designs—including high-Tg copper-clad laminates and independent grounding layers—it can withstand a wide temperature range of -40°C to 85°C, vibration, and high-humidity environments. It also features anti-interference capability and easy maintenance, providing stable hardware support for industrial equipment such as machine tools and robots, and ensuring the efficient operation of intelligent manufacturing.

Benefits

• High-Reliability Design

  Through independent grounding layers, EMC protection, and derating design, it minimizes interference and single-point faults while extending equipment service life.

• Wide Environmental Adaptability

  It utilizes high-Tg copper-clad laminates and special surface treatment, withstanding harsh operating conditions such as a wide temperature range (-40°C to 85°C), high humidity, and vibration.

• Ease of Maintenance


  Test points and clear silkscreen markings are incorporated, facilitating rapid fault location and reducing operation and maintenance costs.
